Name: 4G Bluetooth Padlock - kades locks
SKU: 4GBP
Price: 135.00 USD
Availability: InStock

B:4G Bluetooth Padlock Technical Parameters

Product Name: 4G Bluetooth Padlock
Communication Method: 4G, Bluetooth

1. Lock Beam Material: 304 Stainless Steel; Housing: Zinc Alloy

2. Operating Voltage: 3-5VDC

3. Operating Environment: -40-80℃, 20%-98%RH

4. Number of Opening/Closing Cycles: ≥50,000

5. Battery Specifications: 19000mAh (non-rechargeable), standby time > 3 years

6. Protection Rating: IP67

7. Password Keys: 4-digit password key

8. Signal Transmission: 4G, Bluetooth 4.0 and above

9. Encryption Method: SM4, AES128

10. Applicable Environment: Indoor, Outdoor, etc.

11. Salt Spray Test: Meets GB/T2423 standard requirements, 72 hours or more

12. Operating System: Lock App operation, supports Android and Apple systems

13. Unlocking Methods: Remote, Bluetooth, dynamic password unlocking, electronic key, emergency mechanical key

C:4G Bluetooth Padlock Functional Features and Technical Specifications

Type-C Function:

● The lock contains a built-in battery. In case of power failure, it can be unlocked directly using a mobile phone or power bank via Type-C in an emergency, allowing for normal unlocking.

Durability:

● The lock exhibits no abnormalities under vertical and lateral tensile forces of at least 2000N. It remains undamaged during daily use, impacts, drops, collisions, and vibrations.

Multiple Unlocking Methods:

● 4G remote unlocking, Bluetooth unlocking, dynamic password unlocking, electronic key unlocking, and mechanical key unlocking.

Emergency Unlocking Methods:

● Password Unlocking: Passwords are generated in real-time by the management platform and automatically expire. Supports emergency unlocking by temporary personnel.

● Electronic Key Unlocking: When the battery is dead, an authorized electronic key can be used for unlocking.

● Mechanical Key Unlocking: When the lock system fails, an emergency mechanical key can be used for unlocking.

Functional Features:

● Supports lock/unlock recording, authorized unlocking, and audible alerts.

● Supports tamper alarms, low battery alarms, and gantry-cutting alarms.

● Real-time monitoring and status uploads, including battery level, lock/unlock operation status, and abnormal warnings.

● Fine-grained access control and full-process logging.

● Prevents accidental unlocking.

D:4G Bluetooth Padlock Opening/Locking Procedures and Abnormal Unlocking Instructions

System Input: Enter information such as lock, personnel, and permissions into the system;

Issue the unlocking task process on the platform, including information such as unlocking the lock, the user account, and the lock opening/closing time;

After receiving the task, the operator opens the mobile platform APP and selects the unlocking method according to the actual situation, as follows:

* Remote 4G Unlocking:

① Click the unlock button in the App interface. The command is transmitted remotely to the lock via 4G signal.

② Once the command information is successfully recognized, pull down the lock beam to open the lock.

(Can achieve ultra-long-distance unlocking in areas with 4G signal coverage)

* Mobile App Bluetooth Unlocking:

① Connect the lock to Bluetooth in the APP.

② Click the unlock button.

③ Once the information is successfully recognized, pull down the lock beam to open the lock.

* Scan Code Unlocking:

① Open the mobile App and click the scan button.

② Scan the lock’s associated QR code (must be set up in advance).

③ Once the information is successfully recognized, pull down the lock beam to open the lock.

* Electronic Key Unlocking:

① Connect the corresponding key via Bluetooth within the APP.

② Insert the key into the keyhole at the bottom of the lock.

③ Upon successful information recognition, pull down the lock to open.

Mechanical Key Unlocking:

① There is a mechanical keyhole on the side of the lock.

② Insert the key to unlock.

Press the lock beam; the lock will automatically lock and simultaneously upload the lock opening/closing information to the platform.

Unlocking in Abnormal Situations:
Unlocking without Network:
On-site operators contact management via the system phone, reporting the lock information that needs to be opened. Management generates an emergency unlocking code on the platform and informs the operator. The operator enters the emergency unlocking code on the corresponding lock to open it.

Emergency Unlocking Code Generation Mechanism:
Dynamically generated emergency unlocking codes are generated randomly based on the lock’s registration information and clock information. The emergency unlocking code can be used for a set time and number of uses according to platform settings.

Alarm Contents:
Forced Damage Alarm, Password Trial Alarm, Offline Alarm, Timeout Without Closure Alarm, Low Battery Alarm
